Terrace wood bamboo light
Bamboo decking is extremely durable and robust. The bamboo wood comes from sustainable cultivation. For optimal UV protection, the planks are pre-oiled brown at the factory.
- Durability class: 1-2(very durable)
- Wood colour: dark brown
- Wood structure: fine-pored bamboo fibres
- Gross density: 1100 Kg/m³
- Bending strength: 74,4 N/mm³
- Tolerance: thickness approx. +/- 1 mm | width approx. +/- 2 mm
Hints:
- Bamboo terraces are usually very dimensionally stable, but can under certain circumstances react to thematic influences with expansion and contraction.
- Bamboo is a natural building material. Natural colour differences, slight cupping, transverse curvatures and twisting may occur. This is no reason for complaint. This does not affect the durability and strength of the product.
Recommendation substructure: aluminium
planeo is the brand for professional solutions with tested quality. In our extensive range, you will find first-class products for home and garden, from floors to wall coverings to decking: we offer you suitable items with a top price-performance ratio for almost every requirement and budget. We also have product lines such as carpets, wall paints, wallpapers and doors. The range of attractive offers for walls, floors and patios is rounded out by high-quality accessories and effective cleaning and maintenance products. Meanwhile, planeo's services go beyond the trade in floor coverings. We put great emphasis on the idea of service in everything we do. We deal with the topics of material, handling and realisation in such detail that we can provide you with an adequate solution for many different situations on the building site. To make things more clear, you can find useful tips and instructions in our guides with articles and videos. Beautiful flooring and more? Realise easily with planeo.
| item no. | CT_1850_GG |
|---|---|
| Manufacturer | planeo |
| Length in mm | 1850 |
| Width in mm | 137 |
| Thickness in mm | 20 |
| Top / bottom | smooth/grooved |
| Material | Wood |
| Look | Wood effect |
| Special features | Hardwood, Reversible |
| EAN | 4062212049860 |
| Colour | brown |
| Piece per package | 1 |
| Profiles | Solid plank |
| Shipping group | XL |
| Type | Clip system |
| Weight | 6,04 kg/Packing |
| Wood type | Bamboo |
| suitable for | Pool surround |
| Package Content | 1.85 rm |
|
Show all data ▼
|
|
| Downloads | |
planeo Holz-Terrassendiele Bambus hell - Datenblatt
|
|
|
planeo Holz-Terrassendielen Bambus - Verlegeanleitung
|
|
|
planeo Terrassendielen - Broschüre
|
|
We will help you with your questions!
A specialist adviser will be happy
to advise you personally.
☎ +49 5222 960 4810
Mon - Fri: 9am - 6pm
Sat: 9am - 2pm
Variant: DIY-Instruction
button
Roughly spread the chippings on the compacted gravel with a wheelbarrow and a shovel. Level the surface with a spirit level on two long metal rods embedded in the chippings. Check the required construction height and the slope with at least two taut cords. Start in one corner and work down the entire surface in rows.
button
First roll out a sheet of weed mat, starting from the outer edge. Then lay out the lawn edging stones on the weed fleece at a distance of 35 cm from each other.
Tip: A homemade template can serve as a spacer and make it easier to lay the subsequent lawn edging stones on the fleece.
button
Lay out the terrace pads under the substructure and fix the substructure to the lawn edging stones by pre-drilling and then screwing.
ATTENTION: The distance between the inner edges of the substructures should not exceed 35 cm.
button
If you want lighting, plan the positioning and number of lights. Lay the main cable under the substructure and install the recessed spotlights in the second floorboard. Check the function of the lamps immediately after installation.
button
The planks should lie crosswise to the substructure. Pre-drill the screw holes on the first planks and attach the clips of the plank side facing the wall crosswise to the substructure to the back of the plank. Then fix the planks to the substructure, keeping a distance of approx. 2 cm to the wall. The opposite clips are fixed to the plank in a protruding position (integrated mounting stop on the clip). The installation of the clip on the plank is facilitated by an integrated installation stop and this enables easy positioning. The clips of the planks in the next rows are also screwed in a protruding position. In the next step, the patio recessed spots for the lighting can be attached at the desired location. Finally, cut the edge joints of the planks, this way we get a straight joint.
Material:
- Wooden composite decking boards
- Substructure
- UK connector
- Assembly clips
- Decking pads
- EPDM tape
- Stainless steel screws
optional:
- Weed fleece
- LED lights
- Kerbstones
- Gravel
- Paving chippings
- Concrete slabs
- Dowels
tools:
- Cordless screwdriver
- Spirit level
- Folding rule
- Chop saw
- Tacks / iron rods
- Hearing protection & safety goggles
- Protective gloves
optional:
- Impact drill
- Spade
- Wheelbarrow
- Shovel
- Mason's cord
working time:
- up to 50h per 20m² terrace area
Difficulty level:
- Medium
